Sliding Windows

Aluminium sliding windows are a stylish and functional window option designed with horizontal sashes that glide smoothly along a track. Known for their sleek design and space-saving operation, they are ideal for maximizing views and ventilation without protruding into interior or exterior spaces.

Everything Windows and Doors
Contact Us
Back to all Windows

Sliding Windows

Window Configurations

There are various sliding windows configurations available

Sliding Windows

500 Series Horizontal 2 panel

Description Code Width (mm) Height (mm) Casement Material
2 panel 900mm(W) SW 96, SW 99, SW 912 900 600, 900, 1200 - Aluminium
2 panel 1200mm(W) SW 126, SW 129, SW 1212 1200 600, 900, 1200 - Aluminium
2 panel 1500mm(W) SW 156, SW 159, SW 1512 1500 600, 900, 1200 - Aluminium
2 panel 1800mm(W) SW 186, SW 189, SW 1812 1800 600, 900, 1200 - Aluminium

Sliding Windows

500 Series Horizontal 4 panel

Description Code Width (mm) Height (mm) Casement Material
4 Panel 1800mm(W) SW 1806, SW 1809, SW 1812 1800 600, 900, 1200 - Aluminium
4 Panel 2100mm(W) SW 2106, SW 2109, SW 2112 2100 600, 900, 1200 - Aluminium
4 Panel 2400mm(W) SW 2406, SW 2409, SW 2412 2400 600, 900, 1200 - Aluminium
4 Panel 2700mm(W) SW 2706, SW 2709, SW 2712 2700 600, 900, 1200 - Aluminium
4 Panel 3000mm(W) SW 3006, SW 3009, SW 3012 3000 600, 900, 1200 - Aluminium
4 Panel 3300mm(W) SW 3306, SW 3309, SW 3312 3300 600, 900, 1200 - Aluminium
4 Panel 3600mm(W) SW 3606, SW 3609 3600 600, 900 - Aluminium

Sliding Windows

Elite Horizontal 2 Panel

Description Code Width (mm) Height (mm) Casement Material
2 panel 900mm(W) ELITE906, ELITE909, ELITE912 900 600, 900, 1200 - Aluminium
2 panel 1200mm(W) ELITE1206, ELITE1209, ELITE1212, ELITE1215 1200 600, 900, 1200, 1500 - Aluminium
2 panel 1500mm(W) ELITE1506, ELITE1509, ELITE1512, ELITE1515 1500 600, 900, 1200, 1500 - Aluminium
2 panel 1800mm(W) ELITE1806, ELITE1809, ELITE1812, ELITE1815 1800 600, 900, 1200, 1500 - Aluminium
2 panel 2100mm(W) ELITE2106, ELITE2109, ELITE2112, ELITE2115 2100 600, 900, 1200, 1500 - Aluminium
2 panel 2400mm(W) ELITE2406, ELITE2409, ELITE2412, ELITE2415 2400 600, 900, 1200, 1500 - Aluminium
2 panel 2700mm(W) ELITE2706, ELITE2709, ELITE2712, ELITE2715 2700 600, 900, 1200, 1500 - Aluminium
2 panel 3000mm(W) ELITE3006, ELITE3009, ELITE3012, ELITE3015 3000 600, 900, 1200, 1500 - Aluminium

Sliding Windows

Elite Horizontal 3 Panel

Description Code Width (mm) Height (mm) Casement Material
3 Panel 1800mm(W) ELITE1809, ELITE1806, ELITE1812, ELITE1815 1800 600, 900, 1200, 1500 - Aluminium
3 Panel 2100mm(W) ELITE2109, ELITE2106, ELITE2112, ELITE2115 2100 600, 900, 1200, 1500 - Aluminium
3 Panel 2400mm(W) ELITE2409, ELITE2406, ELITE2412, ELITE2415 2400 600, 900, 1200, 1500 - Aluminium
3 Panel 2700mm(W) ELITE2709, ELITE2706, ELITE2712, ELITE2715 2700 600, 900, 1200, 1500 - Aluminium
3 Panel 3000mm(W) ELITE3009, ELITE3006, ELITE3012, ELITE3015 3000 600, 900, 1200, 1500 - Aluminium
3 Panel 3300mm(W) ELITE3309, ELITE3306, ELITE3312, ELITE3315 3300 600, 900, 1200, 1500 - Aluminium
3 Panel 3600mm(W) ELITE3609, ELITE3606, ELITE3612, ELITE3615 3600 600, 900, 1200, 1500 - Aluminium
3 Panel 3900mm(W) ELITE3909, ELITE3906, ELITE3912, ELITE3915 3900 600, 900, 1200, 1500 - Aluminium
3 Panel 4200mm(W) ELITE4209, ELITE4206, ELITE4212, ELITE4215 4200 600, 900, 1200, 1500 - Aluminium
3 Panel 4500mm(W) ELITE4509, ELITE4506, ELITE4512, ELITE4515 4500 600, 900, 1200, 1500 - Aluminium

Sliding Windows

Elite Horizontal 4 Panel

Description Code Width (mm) Height (mm) Casement Material
4 Panel 1800mm(W) ELITE1806, ELITE1809, ELITE1812 1800 600, 900, 1200 - Aluminium
4 Panel 2100mm(W) ELITE2106, ELITE2109, ELITE2112, ELITE2115 2100 600, 900, 1200, 1500 - Aluminium
4 Panel 2400mm(W) ELITE2406, ELITE2409, ELITE2412, ELITE2415 2400 600, 900, 1200, 1500 - Aluminium
4 Panel 2700mm(W) ELITE2706, ELITE2709, ELITE2712, ELITE2715 2700 600, 900, 1200, 1500 - Aluminium
4 Panel 3000mm(W) ELITE3006, ELITE3009, ELITE3012, ELITE3015 3000 600, 900, 1200, 1500 - Aluminium
4 Panel 3300mm(W) ELITE3306, ELITE3309, ELITE3312, ELITE3315 3300 600, 900, 1200, 1500 - Aluminium
4 Panel 3600mm(W) ELITE3606, ELITE3609, ELITE3612, ELITE3615 3600 600, 900, 1200, 1500 - Aluminium
4 Panel 3900mm(W) ELITE3906, ELITE3909, ELITE3912, ELITE3915 3900 600, 900, 1200, 1500 - Aluminium
4 Panel 4200mm(W) ELITE4206, ELITE4209, ELITE4212, ELITE4215 4200 600, 900, 1200, 1500 - Aluminium
4 Panel 4500mm(W) ELITE4506, ELITE4509, ELITE4512, ELITE4515 4500 600, 900, 1200, 1500 - Aluminium
4 Panel 4800mm(W) ELITE4806, ELITE4809, ELITE4812, ELITE4815 4800 600, 900, 1200, 1500 - Aluminium

Sliding Windows

1000 Series Horizontal 2 Panel

Description Code Width (mm) Height (mm) Casement Material
2 panel 900mm(W) HDSW96, HDSW99, HDSW912 900 600, 900, 1200 - Aluminium
2 panel 1200mm(W) HDSW126, HDSW129, HDSW1212, HDSW1215 1200 600, 900, 1200, 1500 - Aluminium
2 panel 1500mm(W) HDSW156, HDSW159, HDSW1512, HDSW1515 1500 600, 900, 1200, 1500 - Aluminium
2 panel 1800mm(W) HDSW186, HDSW189, HDSW1812, HDSW1815 1800 600, 900, 1200, 1500 - Aluminium
2 panel 2100mm(W) HDSW216, HDSW219, HDSW2112, HDSW2115 2100 600, 900, 1200, 1500 - Aluminium
2 panel 2400mm(W) HDSW246, HDSW249, HDSW2412, HDSW2415 2400 600, 900, 1200, 1500 - Aluminium
2 panel 2700mm(W) HDSW276, HDSW279, HDSW2712, HDSW2715 2700 600, 900, 1200, 1500 - Aluminium
2 panel 3000mm(W) HDSW306, HDSW309, HDSW3012, HDSW3015 3000 600, 900, 1200, 1500 - Aluminium

Sliding Windows

1000 Series Horizontal 3 Panel

Description Code Width (mm) Height (mm) Casement Material
3 Panel 1800mm(W) HDSW186, HDSW189, HDSW1812, HDSW1815 1800 600, 900, 1200, 1500 - Aluminium
3 Panel 2100mm(W) HDSW216, HDSW219, HDSW2112, HDSW2115 2100 600, 900, 1200, 1500 - Aluminium
3 Panel 2400mm(W) HDSW246, HDSW249, HDSW2412, HDSW2415 2400 600, 900, 1200, 1500 - Aluminium
3 Panel 2700mm(W) HDSW276, HDSW279, HDSW2712, HDSW2715 2700 600, 900, 1200, 1500 - Aluminium
3 Panel 3000mm(W) HDSW306, HDSW309, HDSW3012, HDSW3015 3000 600, 900, 1200, 1500 - Aluminium
3 Panel 3300mm(W) HDSW336, HDSW339, HDSW3312, HDSW3315 3300 600, 900, 1200, 1500 - Aluminium
3 Panel 3600mm(W) HDSW366, HDSW369, HDSW3612, HDSW3615 3600 600, 900, 1200, 1500 - Aluminium
3 Panel 3900mm(W) HDSW396, HDSW399, HDSW3912, HDSW3915 3600 600, 900, 1200, 1500 - Aluminium
3 Panel 4200mm(W) HDSW426, HDSW429, HDSW4212, HDSW4215 4200 600, 900, 1200, 1500 - Aluminium
3 Panel 4200mm(W) HDSW456, HDSW459, HDSW4512, HDSW4515 4500 600, 900, 1200, 1500 - Aluminium

Sliding Windows

1000 Series Horizontal 4 Panel

Description Code Width (mm) Height (mm) Casement Material
4 Panel 1800mm(W) HDSW186, HDSW189, HDSW1812 1800 600, 900, 1200 - Aluminium
4 Panel 2100mm(W) HDSW216, HDSW219, HDSW2112, HDSW2115 2100 600, 900, 1200, 1500 - Aluminium
4 Panel 2400mm(W) HDSW246, HDSW249, HDSW2412, HDSW2415 2400 600, 900, 1200, 1500 - Aluminium
4 Panel 2700mm(W) HDSW276, HDSW279, HDSW2712, HDSW2715 2700 600, 900, 1200, 1500 - Aluminium
4 Panel 3000mm(W) HDSW306, HDSW309, HDSW3012, HDSW3015 3000 600, 900, 1200, 1500 - Aluminium
4 Panel 3300mm(W) HDSW336, HDSW339, HDSW3312, HDSW3315 3300 600, 900, 1200, 1500 - Aluminium
4 Panel 3600mm(W) HDSW366, HDSW369, HDSW3612, HDSW3615 3600 600, 900, 1200, 1500 - Aluminium
4 Panel 3900mm(W) HDSW396, HDSW399, HDSW3912, HDSW3915 3900 600, 900, 1200, 1500 - Aluminium
4 Panel 4200mm(W) HDSW426, HDSW429, HDSW4212, HDSW4215 4200 600, 900, 1200, 1500 - Aluminium
4 Panel 4500mm(W) HDSW456, HDSW459, HDSW4512, HDSW4515 4500 600, 900, 1200, 1500 - Aluminium
4 Panel 4800mm(W) HDSW486, HDSW489, HDSW4812, HDSW4815 4800 600, 900, 1200, 1500 - Aluminium
EWD-Sliding-Windows-500-Series

500 Series Horizontal 2 Panel Slider

2 Sliding sashes

Available Widths
900mm to 1800mm

Available Heights
600mm to 1200mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-500-Series-4-Panel

500 Series Horizontal 4 Panel Slider

4 Sliding sashes

Available Widths
1800mm to 3600mm

Available Heights
600mm to 1200mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Elite_2-Panel

Elite Horizontal 2 Panel Slider

2 Sliding sashes

Available Widths
900mm to 3000mm

Available Heights
600mm to 1500mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Elite_3-Panel

Elite Horizontal 3 Panel Slider

3 Sliding sashes

Available Widths
1800mm to 4500mm

Available Heights
600mm to 1500mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Elite_4-Panel

Elite Horizontal 4 Panel Slider

4 Sliding sashes

Available Widths
1800mm to 4800mm

Available Heights
600mm to 1500mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-1000-Series_2-Panel

1000 Series Horizontal 2 Panel Slider

2 Sliding sashes

Available Widths
900mm to 3000mm

Available Heights
600mm to 1500mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-1000-Series_3-Panel

1000 Series Horizontal 3 Panel Slider

3 Sliding sashes

Available Widths
1800mm to 4500mm

Available Heights
600mm to 1500mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-1000-Series_4-Panel

1000 Series Horizontal 4 Panel Slider

4 Sliding sashes

Available Widths
1800mm to 4800mm

Available Heights
600mm to 1500mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Palace-Multi-Horizontal_2-Panel

Palace Multi Horizontal 2 Panel Slider

2 Sliding sashes

Available Widths
900mm to 3000mm

Available Heights
600mm to 1800mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Palace-Multi-Horizontal_3-Panel

Palace Multi Horizontal 3 Panel Slider

3 Sliding sashes

Available Widths
1800mm to 4500mm

Available Heights
600mm to 1800mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Palace-Multi-Horizontal_4-Panel

Palace Multi Horizontal 4 Panel Slider

4 Sliding sashes

Available Widths
1800mm to 4800mm

Available Heights
600mm to 1800mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Palace-Multi-Horizontal-Louvre_2-Panel

Palace Multi Horizontal 2 Panel Slider with Y Louvre Insert

2 Sliding sashes

Available Widths
900mm to 1800mm

Available Heights
600mm to 1800mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Palace-Multi-Horizontal-Louvre_3-Panel

Palace Multi Horizontal 3 Panel Slider with Y Louvre Insert

3 Sliding sashes

Available Widths
1800mm to 3000mm

Available Heights
600mm to 1800mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Palace-Multi-Horizontal-Louvre_4-Panel

Palace Multi Horizontal 4 Panel Slider with Y Louvre Insert

4 Sliding sashes

Available Widths
1800mm to 3900mm

Available Heights
600mm to 1800mm

Sliding Left to Right or Right to Left

EWD-Sliding-Windows-Vertical_Without-Clip-Frame

Vertical without Clip 44 Outer Frame

2 Sliding sashes

Available Widths
600mm to 1200mm

Available Heights
900mm to 1500mm

Sliding Top to Bottom or Bottom to Top

EWD-Sliding-Windows-Vertical_With-Clip-Frame

Vertical with Clip 44 Outer Frame

2 Sliding sashes

Available Widths
600mm to 1200mm

Available Heights
900mm to 1500mm

Sliding Top to Bottom or Bottom to Top

Sliding Windows

Features

  • Catches are black, no other options available (500 Series)
  • Standard handle lock is black, natural handle lock available at additional charge
  • Cylinder (half thumb) is excluded
  • Stainless steel flush pull handles inside only
  • All visible hardware components are black
  • White fitch catch available on request at additional charge (Vertical)
Contact us

Sliding Windows

Specifications

  • All panels slide
  • Burglar bars not compatible with these systems

Sliding Window – 500 Series Horizontal

  • Only available with a double track
  • Indicate number of panels on order

Sliding Windows – Elite Horizontal

  • Triple track available on request

Sliding Windows – 1000 Series Horizontal

  • Panel height of 18oomm available on request

Sliding Windows – Palace Multi Horizontal with Y Louvre Insert

  • Y-Louvre not weatherproof

Sliding Windows – Vertical

  • No change in size due to restriction on spring balances
  • Windows wider than 900mm are fitted with 2 fitch catches
  • Only available in 4mm thickness glass
Heights :
  • 900mm
  • 1200mm
  • 1500mm
Configurations :

Single or Double

Direction :

LH, RH, Center

Colour :
197,185
Glass :

5mm Toughened Glass

Glazing :

Single & Double
